GRÖSSE & PASSFORM

Custom-fit backpacks are Osprey's legacy. Our expertise in designing backpacks that fit every shape, size and gender dates back to 1974, when Osprey was founded on designing custom packs for mountaineers headed to the Sierra.

As the leader in custom-fit backpacks, our pack-fitting technique ensures a properly fitting pack that maximizes efficiency, comfort and safety both on and off the trail.

GRÖSSENÜBERSICHT

Die Passform sollte aus anderen Gründen nicht beeinträchtigt werden. Körperform und -größe variieren von Kunde zu Kunde. Nicht jeder Kunde passt in jede Packung. Mit verstellbaren Rucksäcken können Kunden die Passform für eine optimale Trageleistung optimieren.

TORSO LENGTH

Pack size is based on torso length.

HIPBELT SIZE

The hipbelt size and fit affects how the load transfers from the pack and carries on the hips.

SHOULDER STRAP

The harness size and/or length of the strap affects how the pack stabilizes and wraps around the shoulders.

RÜCKERLÄNGE/GRÖSSE

Many Osprey packs are available in multiple sizes to fit a range of torso lengths. To determine your torso measurement, please see diagram below.

Find iliac crest.
Top of hip bone

On back of neck,
find C7 vertebra.
Touch your chin to your chest and feel the large protruding bone at the base of your neck.

Measure from C7 vertebra to the iliac crest to determine torso length.

HIPBELT SIZING

To determine hipbelt size, measure around the hips at the iliac crest, not the waist. The padded portion should wrap well around the hips, leaving a gap of 3" to 6" between the tips of both hip pads when securely tightened.

FIXED HIPBELT SIZING



XS - 24-25" / 60-114 cm

S - 24-25" / 60-114 cm

S/M - 26-45" / 65-114 cm

M - 27-48" / 69-121 cm

M/L - 28-50" / 70-127 cm

L - 29-55" / 72-140 cm

O/S - 25-50" / 64-127 cm

S/M EF - 17-20.5" / 43-52 cm

L/XL EF - 19.5-23" / 49-58 cm

O/S EF - 40-70" / 101- 177 cm

WXS/S EF - 13.5-17" / 34-43 cm

WM/L EF - 16-19.5" / 40-49 cm



HIPBELT ADJUSTMENT OPTIONS:



Adjustable and custom packs allow you to make sizing adjustments to the hipbelt.

Fit-on-the-Fly Hip belt

Fit-on-the-fly hipbelt™

Adjustable hipbelt

Packs with Fit-on-the-fly adjustable hipbelt: Atmos/Aura AG, Volt/Viva, Ace (Kids), Poco Child Carrier

Interchangeable hipbelt

Interchangeable hipbelt



Packs with an interchangable Hipbelt: Aether/Ariel Pro, Aether/Ariel AG

Item Category Code

Men's sizing

Torso

 Category 14" (35.5cm) 15" (38cm) 16" (40.5cm) 17" (43cm) 18" (46cm) 19" (48cm) 20" (51cm) 21" (53cm) 22" (56cm) 23" (58.5cm) 24" (61cm) 25" (63.5cm)
M Outdoor

AETHER_AETHER_PLS Aether Plus | Aether M Outdoor - - - S/M S/M S/M or L/XL S/M or L/XL S/M or L/XL L/XL L/XL
AETHER_PRO Aether Pro M Outdoor - - S S S or M S or M M or L M or L L L -
ATMOS Atmos AG™ M Outdoor - - - S/M S/M S/M OR L/XL S/M OR L/XL S/M OR L/XL L/XL L/XL -
ATMOS_LT Atmos AG LT M Outdoor - - - S/M S/M S/M S/M L/XL L/XL L/XL -
TALON Talon | Talon Pro M Outdoor - -   S/M S/M S/M or L/XL S/M OR L/XL L/XL L/XL - -
TALON_22_EXTENDED_FIT Talon 6 M Outdoor O/S HIPBELT FIT RANGE IS 25-50" (64-127 CM)
ROOK Rook M Outdoor - - - O/S O/S O/S O/S O/S O/S - -
VOLT Volt M Outdoor - - -   O/S O/S O/S O/S OS - -
EXOSS22 Exos M Outdoor - - - S/M S/M S/M S/M OR L/XL S/M OR L/XL L/XL L/XL -
EXOS_PRO Exos Pro M Outdoor - - - S/M S/M S/M or L/XL S/M OR L/XL L/XL L/XL L/XL -
KESTREL Kestrel M Outdoor - - S/M S/M S/M S/M or M/L S/M or M/L M/L M/L M/L -
UNLTDAGM Osprey UNLTD AG 32 M Outdoor - - - S/M S/M S/M or L/XL S/M OR L/XL L/XL L/XL L/XL -
STRATOS44 Stratos M Outdoor - - - -  O/S O/S O/S O/S O/S - -
SOELDEN Soelden Pro | Soelden M Outdoor - - - O/S O/S O/S O/S O/S O/S - -
KAMBER_16 Kamber 20,30 M Outdoor - - - O/S O/S O/S O/S O/S O/S - -
M Hydration

MANTA Manta | Skarab M Hydration - - - O/S O/S O/S O/S O/S O/S - -
DURO Duro LT, 6, 1.5 M Hydration SMALL (30-35" / 75-90 CM.) MEDIUM (35-41" / 90-105 CM.) LARGE (41-47" / 105-120 CM.)— CHEST MEASUREMENT
DURO Duro 15 M Hydration S/M (30-41" / 76-104 CM.) M/L (41-47" / 104-119 CM.) — CHEST MEASUREMENT
SKARAB_18 RAPTOR | SYNCRO | SISKIN | KATARI M Hydration - - - O/S O/S O/S O/S O/S - - -
M Travel

FARPOINT Farpoint Travel Pack M Travel - - - - O/S O/S O/S O/S O/S - -
FARPNTWHLS Farpoint Trek M Travel - - - O/S O/S O/S O/S O/S O/S - -
OZONE_DUPLEX Ozone Duplex (M) M Travel - - - O/S O/S O/S O/S O/S O/S - -

INTERCHANGEABLE HIPBELT - MEN'S AETHER AG

XS 25-25" / 60-114 cm

S 25-25" / 60-114 cm

S/M 36-45" / 65-114 cm

M 27-48" / 69-121 cm

M/L 28-45 " / 70-127 cm

L 29-55" / 72-140 cm

O/S 25-50" / 64-127 cm

Item Category Code

Unisex sizing

Torso

 Category 14" (35.5cm) 15" (38cm) 16" (40.5cm) 17" (43cm) 18" (46cm) 19" (48cm) 20" (51cm) 21" (53cm) 22" (56cm) 23" (58.5cm) 24" (61cm) 25" (63.5cm)
Outdoor

HIKELITE_18_26 Hikelite 18, 26 U Outdoor - O/S O/S O/S O/S O/S O/S O/S O/S - - -
HIKELITE_28_32 Hikelite 28, 32 U Outdoor - S/M S/M S/M S/M or M/L S/M or M/L M/L M/L M/L - - -
  Glade 5, 12   - - - O/S O/S O/S O/S O/S O/S - - -
  Osprey Sportlite 15, 20   - O/S O/S O/S
 O/S
 O/S
 O/S
 O/S
 O/S
 - - -
  Osprey Sportlite 25, 30   S/M S/M S/M S/M
 S/M or M/L
 M/L
 M/L M/L M/L - - -
  Mutant 22   - - O/S
 O/S
 O/S
 O/S
 O/S
 - - - - -
  Mutant 52, 38   - S/M
 S/M
 S/M
 S/M or M/L
 M/L
 M/L
 M/L
 - - - -
MUTANT_NIMSDAI_90 Mutant Nimsdai 90 U Outdoor S/M S/M S/M S/M OR M/L M/L M/L M/L M/L - - - -
KAMBER_ABS Zealot 30 U Outdoor - - O/S O/S O/S O/S O/S - - - - -
POCO_CHILD_CARRIER Zealot 45 U Outdoor S/M S/M S/M S/M or M/L  M/L  M/L  M/L  M/L - - - -
Trinkrucksäcke

  Duro Dyna Belt   O/S HIPBELT FIT RANGE IS 24 – 45" (60 – 115 CM)
  Raptor Pro   - - - O/S
 O/S
 O/S
 - - - - - -
  Savu   O/S HIPBELT FIT RANGE IS 26 – 50" (66 – 127 CM)
  Seral   O/S HIPBELT FIT RANGE IS 26 – 50" (66 – 127 CM)
Bike Commute

  Radial   - - - O/S
 O/S
 O/S
 O/S
 O/S
 O/S
 - -  -
  Metron 26, 24   - O/S
 O/S
 O/S
 O/S
 O/S
 O/S
 O/S
 - - - -
Child Carrier

METRON Poco, Poco Plus, Poco LT U Active Everyday - O/S O/S O/S O/S O/S O/S O/S - - - -
Item Category Code

Kid's sizing

Torso

 Category 11" (28cm) 12" (30.5cm) 13" (33cm) 14" (35.5cm) 15" (38cm) 16" (40.5cm) 17" (43cm) 18" (46cm) 19" (48cm) 20" (51cm) 21" (53cm) 22" (56cm)
ACE_75 Ace 75 (age 12-17) K Outdoor - - - O/S O/S O/S O/S O/S - - - -
ACE_50 Ace 50 (age 8-14) K Outdoor - - O/S O/S O/S O/S O/S - - - - -
ACE_38 Ace 38 (age 5-11) K Outdoor O/S O/S O/S O/S - - - - - - - -
JET_18 Jet 18 (age 8-14) K Outdoor - - O/S O/S O/S O/S O/S - - - - -
HYDRAJET Hydrajet (age 4-12) K Hydration O/S O/S O/S O/S O/S - - - - - - -
DAYLITE_KIDS Daylite JR (age 4-12) K Outdoor O/S O/S O/S O/S O/S - - - - - - -
MOKI Moki (age 4-12) K Hydration O/S O/S O/S O/S O/S O/S - - - - - -
TALON_TEMPEST_KIDS Talon | Tempest JR (age 8-14) K Outdoor - - O/S O/S O/S O/S O/S - - - - -
Item Category Code

Women's sizing

Torso

 Category 11" (28cm) 12" (30.5cm) 13" (33cm) 14" (35.5cm) 15" (38cm) 16" (40.5cm) 17" (43cm) 18" (46cm) 19" (48cm) 20" (51cm) 21" (53cm) 22" (56cm)
W Outdoor

ARIEL_PLUS Ariel Plus | Ariel W Outdoor - - XS/S XS/S XS/S XS/S or M/L XS/S or M/L M/L M/L M/L - -
ARIEL_PRO Ariel Pro W Outdoor - - - XS XS XS or S XS or S S or M S or M M M -
AURA_AG Aura AG W Outdoor - - XS/S XS/S XS/S XS/S or M/L XS/S or M/L M/L M/L M/L - -
AURA_LT Aura AG LT W Outdoor - - XS/S XS/S XS/S XS/S or M/L XS/S or M/L M/L M/L M/L - -
TEMPEST Tempest | Tempest Pro W Outdoor - - - XS/S XS/S XS/S or M/L XS/S or M/L M/L M/L - - -
TEMPEST_20_EXTENDED_FIT Tempest 6 W Outdoor O/S HIPBELT FIT RANGE IS 24-44" (61-112 CM.)
RENN Renn W Outdoor - - - O/S O/S O/S O/S O/S O/S - - -
VIVA Viva W Outdoor - - - - O/S O/S O/S O/S O/S - - -
EJA Eja W Outdoor - - XS/S XS/S XS/S XS/S or M/L XS/S or M/L M/L M/L M/L - -
EJA_PRO Eja Pro W Outdoor - - XS/S XS/S XS/S XS/S OR M/L XS/S OR M/L M/L M/L M/L - -
KYTE Kyte W Outdoor - - XS/S XS/S XS/S XS/S or S/M XS/S or S/M S/M S/M S/M - -
UNLTD_AGW Osprey UNLTD AG 32 M Outdoor - - XS/S XS/S XS/S XS/S or M/L XS/S or M/L M/L M/L M/L - -
SIRRUS Sirrus W Outdoor - - - - O/S O/S O/S O/S O/S - - -
SOPRIS Sopris Pro | Sopris W Outdoor - - - O/S O/S O/S O/S O/S O/S - - -
KRESTA_20_30 Kresta 20, 30 W Outdoor - - - O/S O/S O/S O/S O/S O/S - - -
W Hydration

VIVA_EXTENDED_FIT Mira W Outdoor - - - O/S O/S O/S O/S O/S - - - -
  Skimmer   - - - - O/S O/S O/S O/S - - - -
  Dyna LT, 6, 1.5   SMALL (26-30" / 65-75 CM.) MEDIUM (30-35" / 75-90 CM.) LARGE (35-41" / 90-105 CM.)— CHEST MEASUREMENT
  Dyna 15   S/M (26-35" / 66-90 CM.) M/L (35-41" / 90-104 CM.) — CHEST MEASUREMENT
  Raven | Sylva | Salida | Kitsuma   - - - O/S O/S O/S O/S O/S - - - -
W Travel

FAIRVIEW Fairview Travel Pack W Travel - - - - O/S O/S O/S O/S O/S - - -
FARVIEW_TREK Fairview Trek W Travel - - - O/S O/S O/S O/S O/S O/S - - -
OZONE_DUPLEX Ozone Duplex (W) W Travel - - - O/S O/S O/S O/S O/S O/S - - -

INTERCHANGEABLE HIPBELT - WOMEN'S ARIEL AG

XS 24-45" / 60-114 cm

S 25-45" / 60-114 cm

S/M 26-45" / 65-114 cm

M 27-48" / 69-121 cm

M/L 28-50 " / 70-127 cm

L 29-55" / 72-140 cm

O/S 25-50" / 64-127 cm

VESTPACK SIZING

The Duro/Dyna 6, 1.5 and LT come in six sizes: men’s S, M, L and women’s S, M, L; the Duro/Dyna 15 comes in four sizes: men’s S/M and M/L and women’s S/M and M/L. Based on torso length and chest circumference, these packs are sized like apparel. The surface area of the harness evenly distributes the weight of the pack on both the smaller and larger volumes. Measurements should be taken at widest part of chest slightly below armpits.

MEN'S DURO 15
SIZE INCHES CENTIMETRES
s/m 29.5 - 41 in 75 - 105 cm
m/l 41 - 47 in 105-120 cm
MEN'S DURO 6 | 1.5 | LT
SIZE INCHES CENTIMETRES
S 29.5 - 35 in 75 - 90 cm
M 35 - 41 in 90 - 105 cm
L 41 - 47 in 105 - 120 cm
WOMEN'S DYNA 15
SIZE INCHES CENTIMETRES
S/M 26 - 35 in 65 - 90 cm
M/L 35 - 41 in 90 - 105 cm
WOMEN'S DYNA 6 | 1.5 | LT
SIZE INCHES CENTIMETRES
S 26 - 29.5 in 65 - 75 cm
M 29.5 - 35 in 75 - 90 cm
L 35 - 41 in 90 - 105 cm

PACK FITTING INSTRUCTIONS

1. POSITION THE PACK

Completely loosen the pack's hipbelt, harness and load-lifter straps. Load the pack with 10-20 lbs./4- kg. of gear. Put the pack on and make sure the hipbelt is centered and rests over the hipbone. The hipbelt padding should sit halfway above/below the hipbone.

2. BUCKLE HIPBELT

Buckle and tighten the hipbelt evenly using the cross-body Ergo-Pull. The padding of the hipbelt should wrap around the hips with approximately 1-3in./2.5-6cm. of webbing between the buckle and the hipbelt when tightened.

3. HIPBELT ADJUSTMENT

If the hipbelt is too large and "tops out" or does not offer the preferred amount of coverage, you may need a different pack size, model or adjustment(Fit-On-The-Fly hipbelt imaged).

4. TIGHTEN SHOULDER STRAP

Tighten the shoulder harness straps by pulling them down and back.

5. TIGHTEN LOAD LIFTERS

Tightening the load lifters will pull the pack close to the body and help stabilize the load. If the torso length on the pack is adjusted correctly, the load lifters will sit between ad 30- to 60-degree angle and align naturally with the shoulder straps.

6. CHECK TORSO LENGTH

Locate the harness yoke—this is where the harness straps come together near the base of the neck. Locate the C7 vertebra—the large protruding bone at the base of the neck. The yoke should be 1in./2.5 cm. to 2 in./5 cm below the C7 vertebra

7. TORSO LENGTH-HARNESS ADJUSTMENT

If the torso length is too long or too short, you may need a different pack size, model or an adjustment. Consider making an adjustment if:

  • Load lifters are angled below/above 30-60 degrees
  • Yoke to C7 vertebra dsitance is more than 2 in./5 cm. or less than 1 in./2.5 cm.
  • There is a gap between the harness and back of the shoulder

8. CHECK HARNESS FIT

The harness straps should wrap fully around the shoulders with no gaps between the pack and back. The padded part of the shoulder straps should end at 2 in./5 cm. below the armpits without topping out.

9. HARNESS/SHOULDER STRAP ADJUSTMENT

If the harness is too small or too large, but the torso length of the pack is correct, you may need a different pack size, model or adjustment (Fit-On-The-Fly™ shoulder strap imaged).

10. BUCKLE THE STERNUM STRAP

Adjust the sternum strap to approximately 2 in./5 cm. below the collarbone.

EXTENDED FIT PACKS

Our EF collection adds new sizing to core packs, providing people in larger bodies the same uncompromised performance with an Exclusive fit.
Search for Extended Fit packs at osprey.com or look for the EF icon when shopping in store.

EF logo EF

STANDARD
EXTENDED HIPBELT FITS UP TO 70-INCH HIPS.

Substantially longer padding provides comfort, support and stability.

EF logo EF

STANDARD
REPOSITIONED POCKETS

Hipbelt pockets have been shifted forward for practical, easy-to-reach access.

EF logo EF

STANDARD
EXTENDED SHOULDER STRAPS

Längere Schultergurte verteilen die Last gleichmäßig und komfortabel.

EF logo EF

STANDARD
LONGER STERNUM STRAP

Ein längerer Brustgurt erhöht die Stabilität, ohne einzuengen.

CONVENTIONAL TORSO RANGE

Extended Fit uses our standard torso range to fit a wide variety of heights. Follow our standard Torso Fit instructions to find your size.

FAQ ABOUT EXTENDED FIT (EF)

Q - DO EXTENDED FIT PACKS COST MORE THAN OTHER SIZES?

A - Not at all! We firmly believe that there's no reason to charge people more, just for having a bigger body. Extended Fit is just a new sizing option to help more people find comfort, joy and adventure outdoors-not an upsell.

Q - WHAT IF I FALL BETWEEN EXTENDED FIT AND YOUR STANDARD FIT SIZES?

A - There is some overlap between our Extended Fit sizing and our other sizing. If you fall within this overlap, you may consider whether you'd benefit from any of the Extended Fit features, such as repositioned hipbelt pockets or extended shoulder straps, to help decide what would be most comfortable and effective for you. Of course, nothing beats trying packs on in store.

Q - HOW DO I KNOW WHICH EXTENDED FIT SIZE I SHOULD ORDER?

A - While some Extended Fit packs come in one size, there are several with different EF size options. These sizes refer to the torso length of the pack, not your waist size or chest size. If you have a shorter torso length, a smaller pack size will likely fit you best. People with longer torsos will find that larger pack sizes fit best. Visit our Size Guide for guidance on measuring your torso or visit a retailer for help.

Q - WHERE CAN I BUY EXTENDED FIT PACKS?

A - Extended Fit packs are available at select retailers, where you can try on different packs and sizes with the help of a trained employee. Find a retailer near you and call ahead to confirm inventory. Extended Fit is also available online at osprey.com where we offer free shipping and returns so you can find the right size for you from the comfort of home, hassle free.

WOMEN'S-SPECIFIC FIT

For more than 25 years, Osprey has been designing packs for women. We understand that body-specific fit crucial to your experience on the trail. Our women's-specific torso, harness and hipbelt ensure a proper fit to maximize efficiency, comfort, and safety.

  • Shorter torso length
  • Narrower, shorter harness with curves designed to accommodate most women's necks, shoulders and chests.
  • A hipbelt designed to wrap naturally around the curves of woman's hips, offering better load stabilization and support.

MOUNTAIN BIKE PACK FIT

1. POSITION THE PACK

The backpanel and harness straps should wrap fully around your shoulders with no gaps between the pack and your back.

2. ADJUST THE PACK

The padded part of the harness straps should end 1"/2.5 cm - 2"/5 cm below the armpits.

3. BUCKLE THE STERNUM STRAP

The sternum strap adjusted to approximately 2"5 cm below the collarbone.

MOUNTAIN BIKE LUMBAR PACK FIT

1. BUCKLE THE HIPBELT

Buckle and tighten the hipbelt using the cross-body Ergo-Pull. the padding of the hipbelt should wrap around the hips with approximately 1-3 in./2.5-6 cm. of webbing between the buckle and the hipbelt when tightened. Breathable airmesh wrap hipbelt contours over the hipbone to provide a comfortable, secure and stable carry.

2. ADJUST THE WAIST STRAPS

ErgoPull waist closure system allows for proper snug and stable fit

TRAIL RUNNING PACK FIT

1. POSITION THE PACK

This pack anchors to the rib cage to prevent unwanted bouncing. To do this, it needs to sit higher on your torso than a typical hiking pack. When first putting on your pack, make sure the top of the pack sits just below the base of your neck

2. POSITION DUAL CHEST STRAPS

Buckle both sternum straps, leaving the webbing a little loose for now. The top chest strap should be positioned 1-2 in./2.5-5 cm. below the collarbone. The bottom chest strap can be moved up toward the middle of the harness to accommodate free and easy breathing; however, keep it down low if pack stability is your primary concern. For women, adjust the chest strap position so that it fits comfortably and keeps the pack snug.

3. TIGHTEN CHEST STRAPS

Before tightening the chest straps, make sure you have completely loosened the under-arm side body straps on each side of the pack. With the chest strap positioned appropriately, pinch the end of the webbing with your thumb and index finger and pull the strap until the tension pulls the strap from your grasp. This helps avoid overtightening the pack. Make small adjustments as necessary to ensure a secure fit.

4. TIGHTEN SIDE BODY STRAPS

Pull the side body straps that connect the harness and pack under each arm. This will pull the lower portion of the pack against the body and snug the pack around your ribcage. Double-check the chest harness strap positioning and tension to ensure optimal fit, comfort and stability.

5. TIGHTEN SHOULDER HARNESS STRAPS & HIPBELT

Cinch the harness to hipbelt strap after fitting the chest straps. Then, buckle and tighten the hipbelt buckle. It is not as important to place directly over the iliac crest (hip bone) as the weight is being supported by the shoulder harness.

6. RESERVOIR HOSE MAGNET PLACEMENT

loader
Wird geladen …
